Where gravity loses its grip: Ultra-strength meets unprecedented lightness.
✓ 140MPa Crushing Strength - Highest load capacity
✓ 2150kg/m³ Density - 25% lighter than standard UHPC
✓ Century Durability - 100+ year service life in harsh environments
✓ Carbon Efficiency - 30% lower embodied CO₂ vs traditional UHPC
Product Introduction
When engineers needed to extend the lifespan of this iconic structure without adding dead load:
28% weight reduction vs conventional concrete
140MPa strength ensured seismic resilience
Chloride diffusion coefficient 5x lower than spec
Projected maintenance savings: $17M over 50 years
Nano-reinforced matrix
Silica fume particles (0.1-0.3µm) fill micro-voids
Hybrid fiber network
Steel + PVA fibers control crack propagation
Cellular lightweight aggregate
Shale ceramsite reduces mass without sacrificing strength
Product Parameters
| Grade | Compressive strength (MPa) | Flexural strength (MPa) | Density (kg/m3) |
| C100 | 80(7d)/100 (28d) | 11(7d)/15 (28d) | 1950 |
| C120 | 96 (7d)/120 (28d) | 14 (7d)/18 (28d) | 2050 |
| C140 | 105 (7d)/140 (28d) | 16(7d)/ 20 (28d) | 2150 |
Advanced Properties
Chloride ion penetration: <100 Coulombs (ASTM C1202)
Freeze-thaw resistance: >95% RDM after 300 cycles (ASTM C666)
Abrasion resistance: <0.1mm loss (ASTM C944)
Product Usage
Precast Workflow Advantage
Design Phase
25% dead load reduction → smaller foundations
Higher strength → slimmer structural elements
Construction Phase
Lighter precast units → lower crane capacity required
3-day demolding time → 50% faster production cycles
Packed in composite bag, net weight 25kg/bag, shelf life 6 months; must be stored in dry and ventilated room, the bag is sealed, pay attention to moisture-proof, anti-freezing.
