F-3 Fluorocarbon Topcoat delivers exceptional anti-corrosion and decorative performance for demanding outdoor applications.
Product Introduction
High-Performance Design: Engineered for superior anti-corrosion, decorative, and mechanical properties, providing reliable long-term protection in demanding outdoor environments.
Exceptional Durability: Offers outstanding resistance to UV radiation and environmental stability, ensuring performance in harsh corrosive conditions or areas with high aesthetic demands.
Versatile Use Cases: Perfect for bridge steel structures, concrete exterior walls, architectural venues, railings, port facilities, and marine equipment.
Industrial Environments: Excels in severe settings such as steel structures, bridge projects, marine facilities, offshore platforms, port terminals, steel buildings, municipal engineering, highway railings, and concrete anti-corrosion protection.
Corrosion Resistance: Provides excellent protection against acids, alkalis, saltwater, gasoline, diesel, and strong corrosive solutions.
Decorative Options: Available in various colors and metallic finishes, with long-term color stability and gloss retention to prevent fading.
Weather Resistance: Delivers high durability against UV and weather elements, offering up to 20 years of reliable performance.
Self-Cleaning Properties: Features a smooth surface that reduces dirt adhesion, making it easy to clean and maintain a fresh appearance.
Mechanical Strength: Meets standards for strong adhesion, impact resistance, and flexibility to ensure coating integrity.
Compatibility: Works seamlessly with common primers like epoxy zinc-rich and intermediate coats such as epoxy micaceous iron.
Product Parameters
| Test Items | Technical Requirements |
|---|---|
| Non-volatile Matter Content (%) | ≥50% |
| Fineness (μm) | ≤35μm |
| Tensile Strength (MPa) | ≥10MPa |
| Elongation at Break (%) | ≥150% |
| Low-Temperature Flexibility (-30°C) | ≤2mm (no cracking) |
| Alkali Resistance (2% NaOH, 10 days) | No blistering, cracking, or peeling on the surface |
| UV Aging Resistance (1000h) | No visible changes |
Product Usage
Substrate Preparation: Thoroughly clean metal surfaces of oil, oxidation, rust, and old coatings using shot blasting (Swedish standard Sa2.5, roughness 30-70μm) or manual rust removal (Swedish standard ST3, roughness 30-70μm). Apply the coating within 4 hours after treatment; if relative humidity exceeds 60%, do not delay beyond 12 hours. Re-treat if moisture condensation occurs.
Paint Mixing: Combine main component and hardener at a 10:1 ratio, add special fluorocarbon thinner, and stir thoroughly with a power mixer. Allow to stand for 20 minutes for optimal integration.
Coating Application: First apply epoxy zinc-rich primer and epoxy micaceous iron intermediate coat in 1-2 layers for a solid anti-corrosion base. Then spray 1-2 coats of F-3 Fluorocarbon Topcoat to achieve a recommended film thickness of 60μm, ensuring complete coverage, smooth surfaces, and no defects like bubbles or orange peel.
Precautions: Use mixed paint within pot life and discard if gelled; avoid application in rain, snow, wind, or humidity >85%; maintain substrate temperature ≥3°C above dew point; keep tools clean and dry; data based on testing for reference only.
Safety Instructions: Avoid skin/eye contact—rinse with warm water or detergent if needed and seek medical help for eyes; ensure ventilation; keep away from flames and comply with local regulations.
Packaging & Storage: AB two-component packaging (Component A: 20kg/barrel, Component B: 3kg/barrel); store in cool, ventilated area away from sunlight with 12-month shelf life.
