HP-1 low viscosity high strength epoxy injection resin penetrates fine cracks effortlessly while providing robust structural support.
Ultra-low <30 mPa·s viscosity for superior flow into micro-cracks.
High ≥50 MPa compressive strength for long-lasting repairs.
Excellent wet/dry bond (≥2.0 MPa wet) resists water and chemicals.
Over 30 minutes operable time with easy 3:1 mixing ratio.
Product Introduction
HP-1 epoxy injection resin stands out for its low viscosity under 30 mPa·s paired with high compressive strength over 50 MPa, making it a top choice for concrete crack repairs where deep penetration and durability matter.
As a two-component system mixed at 3:1, it flows into narrow voids without effort, curing to a tough bond that enhances structural stability in environments like bridges or basements.
This resin excels in wet conditions, offering impermeability above 300% and resistance to shrinkage, ensuring reliable performance for professionals seeking efficient, high-strength solutions.
Product Parameters
| Property | Value | Unit |
| Density | >1.00 | g/cm³ |
| Initial Viscosity | <30 | mPa·s |
| Operable Time | >30 | min |
| Compressive Strength | ≥50 | MPa |
| Tensile Shear Strength | ≥5.0 | MPa |
| Tensile Strength | ≥10 | MPa |
| Bond Strength (Dry) | ≥3.0 | MPa |
| Bond Strength (Wet) | ≥2.0 | MPa |
| Anti-Pull Strength | ≥1.0 | MPa |
| Impermeability Pressure Ratio | ≥300 | % |
| Mixing Ratio (A:B) | 3:1 | by weight |
| Packaging | 12kg kit (9kg A, 3kg B) | - |
Product Usage
Clean the crack surface thoroughly and install injection ports. Mix A and B at 3:1 by weight until uniform. Inject using low-pressure tools for full penetration, starting from the lowest point. Cure for 24 hours at room temperature before loading, with full strength in 7 days. Use protective gear and test compatibility first.
Packaging and Storage:
Component A: 9kg/drum
Component B: 3kg/drum
Shelf Life: 12 months in proper storage conditions
